奥升德 VYDYNE PA66 22HSP 耐化学 润滑 耐磨 高强度 刚性 韧性
Vydyne®22HSP系列具有高强度、刚性、使用韧性好、熔点高、表面润滑性好、耐磨性好等工程性能,是一种很好的平衡组合。此外,它是耐许多化学品和溶剂,包括汽油,机器和机油。
全国24小时销售热线:
18925783032
奥升德VYDYNE®PA66 22HSP物性表参数
产品应用 | Vydyne®22HSP系列树脂可以减少或消除模具释放喷剂的需求。在常规生产基础上实施较短的成型周期之前,应根据规范检查关键的成型零件尺寸。 | |||
性能 | 测试条件 | 单位 | 标准 | 数值 |
密度 | g/cm³ | ISO 1183 | 1.14 | |
拉伸模量 | (23°C) | (MPa) | ISO 1133 | 3100 |
简支梁缺口冲击强度 | 23°C | (kJ/m²) | ISO 180/1A | 85 |
抗张强度 | 23°C | MPa | ASTM D638 | 50 |
热变形温度A法 | 未退火 | °C | (1.80MPa) | 195 |
可燃性(UL94) | class | IEC 60695-11-10 | HB |
奥升德Ascend的Vydyne泛达®PA66 22HSP注塑参数如下表
密度 | 1.01~1.23 | 模具温度 | 80.0 到 100°C | ||
加工(熔体)温度 | 285 到 305°C | 注射压力 | 230 到 250°C | ||
预热 | 温度/°C | 130°C | 工 艺 参 数 | 注射时间 | 20~90 |
时间/h | 4.0hr | 高压时间 | 0~5 | ||
料桶温度/°C | 后段 | 193 到 238°C | 冷却时间 | 20~90 | |
中段 | 280 到 310°C | 总周期 | 220 到 260°C | ||
前段 | 280到 310°C | 螺杆转数 | 30 到 60rpm | ||
喷嘴温度 | 280 到 310°C | 使用注射机类型 | 螺杆式 |
通用注塑
泛达® 22HSP
Vydyne® 22HSP is a heat stabilized molding grade nylon 6,6 resin. It is lubricated for improved machine feed and mold release and is intended for use in applications requiring fast molding cycles and outstanding mold release performance. The stabilization package has been formulated to provide improved retention of physical and electrical properties, compared to non-heat stabilized grades during long term exposure to high temperatures.
The Vydyne® 22HSP series offer a well balanced combination of engineering properties characterized by high strength, rigidity, good toughness in use, high melting point, good surface lubricity, and abrasion resistance. In addition, it is resistant to many chemicals and solvents, including gasoline, and machine and motor oils.
应用
The Vydyne® 22HSP series resins can reduce or eliminate the need for mold release sprays. Critical molded part dimensions should be checked against specifications before implementing shorter molding cycles on a routine production basis.
奥升德VYDYNE®PA66 22HSP是一种热稳定成型级尼龙6,6树脂。它是用于改进的机器进料和模具释放润滑,用于需要快速成型周期和卓越的模具释放性能的应用。与长期暴露在高温下的非热稳定等级相比,所述稳定包的配方可提高物理和电气性能的保持性。
Vydyne®22HSP系列具有高强度、刚性、使用韧性好、熔点高、表面润滑性好、耐磨性好等工程性能,是一种很好的平衡组合。此外,它是耐许多化学品和溶剂,包括汽油,机器和机油。
